Supply Ability:300000 Square Meter/Square Meters per Month LED SMD PCB BOARD
Packaging & Delivery
Packaging Details
Vacuum sealed packaging,Silica Gel inside.
Port
shenzhen/hongkong


Product Type:  AI Clad PCB 1 layer Maximum Panel Size 1470mm*600mm
Finished Board Thickness: 0.4mm to 0.4mm Copper Thickness 0.5oz,1oz,2oz,3oz
Thickness Tolerance: +/-10% Min.Finish hole size 0.25mm
Min.Track Width: 0.2mm(8mils) Min.Track gap 0.mm(8miles)
Min.SMD pad pitch: 0.2mm(8mils) Dielectric Thickness(to Substrate) 0.05mm,0.075mm,0.1mm,0.15mm,0.2mm
Substrate Core Thickness: 0.4mm ,0.6mm 0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,3.0mm,3.2mm
Aluminum Machining: Drilling, Tapping, Milling, Routing, Die-Punching, break-off tab available
Max.working voltage: 2.5K VDC(0.75mm Dielectric)3.75K VDC(0.15mm Dielectric)
Solder mask color:

White, LED light special White, Black, MATT Black, others Available
